Nvidia GeForce RTX 2060 12GB Features
The Nvidia GeForce RTX 2060 12GB features Turing 12nm architecture with 2176 CUDA Cores. It has a base clock of 1470 MHz as well as a boost clock of 1650 MHz. There are 10.8 Billion transistors, 136 Texture Units and additionally 48 ROPs. The memory powering this card is 12GB of GDDR6 memory which is clocked at 14000 MHz effective. The memory interface width is 192-bit and it has a memory bandwidth of 336 GB/s.
The Nvidia GeForce RTX 2060 12GB is a desktop GPU from the GeForce 20 series using a die size of 445 mm². Its codename is TU106-300-KA-A1 and the fabrication process uses TSMC 12nm. The amount of ray tracing cores is 34 as well as 272 tensor cores. The amount of L2 cache comes in at 3MB.
The theoretical performance is based on the clock speed, cores and the floating point operations per clock cycle. The FP16 half precision theoretical performance is 14.3616 TFLOPS, the single precision comes in at 7.1808 TFLOPS and the double precision FP64 performance is 0.2244 TFLOPS. The floating point operations per clock cycle come in at 4 for half precision FP16, 2 is for single precision FP32 and for the double precision it comes in at 1/16. The texture fillrate is 224.4 GT/s and the pixel fillrate is 79.2 GP/s.
In terms of technologies on this card, there is DirectX 12, G-Sync, Open CL 1.2, OpenGL 4.6 and also Shader Model 6.5. This card is VR Ready according to Nvidia. Furthermore, there are extra technologies which include Real-Time Ray Tracing, NVIDIA GeForce Experience, NVIDIA Ansel, NVIDIA Highlights, Game Ready Drivers, Microsoft DirectX 12 Ultimate, Vulkan API, HDCP 2.2, NVIDIA GPU Boost, Designed for USB Type-C and VirtualLink as well as NVIDIA Encoder (NVENC) (Turing).
The maximum digital resolution of the Nvidia GeForce RTX 2060 12GB is 7680×4320. This can be done with the I/O included which are DisplayPort 1.4a, HDMI 2.0b, Dual Link DVI-D and also USB-C. This card does not feature any single link DVI or VGA ports.
3840×2160 @ 60 Hz is the maximum HDMI resolution achievable and 7680×4320 @ 120 Hz is the maximum display port resolution.
To power this card you need 1 x 8 pin connector available. This is because the graphics card has a TGP of 185 W which means the recommended power supply is 500 W. This card comes in at 4.435” (112.6mm) x 9.0” (228.60mm) x 2-Slot. At release, on the 7th December 2021, the card retailed at $299 USD.
