Nvidia GeForce RTX 3090 Ti 24GB

Nvidia GeForce RTX 3090 Ti 24GB
SKU: Nvidia-RTX-3090Ti-24GB
Brand: Nvidia
Category: Graphics Cards
  • Cores: 10752 CUDA Cores
  • Base Clock: 1.67 GHz
  • Boost Clock: 1.86 GHz
  • Memory: 24GB GDDR6X
  • VR Ready: Yes
  • Resolutions Supported: 7680x4320

GPUSpecs's Rating

The rating given by GPUSpecs

9
  • Speed 10 / 10
  • Price 8 / 10
  • Performance 10 / 10
  • Design 8 / 10

Nvidia GeForce RTX 3090 Ti 24GB Specs

The Nvidia GeForce RTX 3090 Ti features ampere 8nm technology powered by 10752 cuda cores. It has a base clock of 1.67 GHz and a boost clock of 1.86 GHz. There are 28.3 billion transistors on the board with 336 texture units and 112 ROPs.

For memory, the Nvidia GeForce RTX 3090 Ti has a huge 24GB of fast GDDR6X VRAM running at 21000 MHz effective memory clock. The memory interface width is 384-bit and the bandwidth is 1008 GB/s.

There are many Nvidia technologies on the Nvidia GeForce RTX 3090 Ti graphics card. The DirectX version is 12 ultimate and it has G-Sync for seamless integration with monitors. It features OpenCL 3.0, OpenGL 4.6, Shader Model 6.6 and is also SLI and VR ready. Other technologies include: Ray Tracing Cores, 2nd Generation, Tensor Cores, 3rd Generation, NVIDIA DLSS, NVIDIA Reflex, NVIDIA Broadcast, PCI Express Gen 4 , Resizable BAR, NVIDIA GeForce Experience, NVIDIA Ansel, NVIDIA FreeStyle, NVIDIA ShadowPlay, NVIDIA Highlights, Game Ready Drivers, NVIDIA Studio Drivers, NVIDIA Omniverse, NVIDIA GPU Boost , Vulkan RT API, OpenGL 4.6, NVIDIA Encoder, 7th Generation and NVIDIA Decoder 5th Generation.

For connectivity, it has DisplayPort 1.4a which can achieve a maximum digital resolution of 7680×4320. It also includes HDMI 2.1. There is no USB-C, DVI or VGA.

In order to power this card, you will need at least an 850 W PSU as the graphics card power is 450 W. You also will require 3 x 8 pin connectors or a 450W or greater PCI-e Gen 5 Cable. In order to get the full potential of the Nvidia GeForce RTX 3090 Ti you will require a PCI-e 4.0 x16 slot.

The Nvidia GeForce RTX 3090 Ti comes in at 12.3″ (313mm) by 5.4″ (138mm). It is a 3 slot card. At release, on the 27th January 2022 this card retailed for $1999 USD. Check more RTX 3090 Ti cards here.

Specifications

Purchase This Card

Amazon View Price At Amazon

General

Manufacturer Nvidia
Type Desktop
Series GeForce 30
Variant RTX 3090 Ti
GPU Architecture Ampere
Code Name GA102-350-A1
Fabrication Process Samsung 8nm
Die Size 628.4 mm²
Base Clock 1.67 GHz
Boost Clock 1.86 GHz
Transistor Amount 28.3 billion

Cores & Texture Config

Cores 10752 CUDA Cores
Texture Units 336
ROPs 112
Ray Tracing Cores 84
Tensor Cores 336
Compute Units -
L2 Cache 6MB
Infinity Cache -

Memory

Memory Size 24GB
Memory Type GDDR6X
Memory Clock 1313 MHz
Memory Clock Effective 21 Gbps
Memory Interface Width 384-bit
Memory Bandwidth 1008 GB/s

Performance

Half Precision FP16 39.9974 TFLOPS
Single Precision FP32 39.9974 TFLOPS
Double Precision FP64 0.62496 TFLOPS

Floating Point Operations Per Clock Cycle

Half Precision FP16 2
Single Precision FP32 2
Double Precision FP64 1/32

Fillrate

Texture (GT/s) 624.96
Pixel (GP/s) 208.32

Technologies

DirectX® Version 12
G-Sync/FreeSync
OpenCL 3.0
OpenGL 4.6
Shader Model 6.6
Vulkan 1.3
SLI/Crossfire Ready
VR Ready
RGB Lighting
Extra Technologies Ray Tracing Cores, 2nd Generation, Tensor Cores, 3rd Generation, NVIDIA DLSS, NVIDIA Reflex, NVIDIA Broadcast, PCI Express Gen 4 , Resizable BAR, NVIDIA GeForce Experience, NVIDIA Ansel, NVIDIA FreeStyle, NVIDIA ShadowPlay, NVIDIA Highlights, Game Ready Drivers, NVIDIA Studio Drivers, NVIDIA Omniverse, NVIDIA GPU Boost , Vulkan RT API, OpenGL 4.6, NVIDIA Encoder, 7th Generation, NVIDIA Decoder 5th Generation

Connectivity

Maximum resolution 7680x4320
Max HDMI Resolution 7680 x 4320 @ 60Hz
Max DP Resolution 7680 x 4320 @ 120Hz
Display Port 1.4a
HDMI 2.1
USB-C No
Dual Link DVI No
Single Link DVI No
VGA No

Requirements

Interface PCIe 4.0 x16
Power Connectors 3 x 8 pin OR 450W or greater PCIe Gen 5 cable
PSU Recommendation 850 W
Graphics Card Power 450 W

Dimensions

Length 12.3" (313 mm)
Width 5.4" (138 mm)
Height 2.4" (61mm)
Slot Width 3 Slot

Extra Information

Price (at release) $1999 USD
Weight 1.677kg
Released 27 January, 2022
