Nvidia GeForce GTX 1630 4GB

Nvidia GeForce GTX 1630 4GB
SKU: Nvidia-GTX-1630-4GB
Brand: Nvidia
Category: Graphics Cards
  • Cores: 512 CUDA Cores
  • Base Clock: 1.74 GHz
  • Boost Clock: 1.785 GHz
  • Memory: 4GB GDDR6
  • VR Ready: No
  • Resolutions Supported: 7680x4320

GPUSpecs's Rating

The rating given by GPUSpecs

5.5
  • Speed 6 / 10
  • Price 6 / 10
  • Performance 4 / 10
  • Design 6 / 10

Nvidia GeForce GTX 1630 4GB Specs

The Nvidia GeForce GTX 1630 is based on the Turing 12nm architecture with 512 CUDA cores. It has a base clock of 1.74 GHz and a boost of 1.785 GHz. There are 4.7 billion transistors on this card in addition to 32 texture mapping units and 16 ROPs. Nvidia’s GeForce GTX 1630 has a memory size of 4GB running at 12000 MHz effective. The memory is GDDR6 video memory with an interface width of 64-bit and a bandwidth of 96 GB/s.

The Nvidia GeForce GTX 1630 runs DirectX version 12 and supports Nvidia’s G-Sync. There is OpenCL 3.0, OpenGL 4.6 and Shader Model 6.7 in addition to Ray Tracing Cores, Tensor Cores, NVIDIA DLSS, NVIDIA Reflex, NVIDIA Broadcast, PCI Express Den 3, Resizable BAR, NVIDIA GeForce Experience, NVIDIA Ansel, NVIDIA Freestyle, NVIDIA Shadowplay, NVIDIA Highlights, Game Ready Drivers, NVIDIA Studio Drivers, NVIDIA Omniverse, NVIDIA GPU Boost, NVIDIA NVLink (SLI-Ready), NVIDIA Encoder(NVENC) and NVIDIA Decoder(NVDEC). There is no SLI and this card is not VR Ready.

The maximum resolution you can get from the Nvidia GeForce GTX 1630 4GB is 7680×4320 @ 60Hz. For display outputs, it has Display Port 1.4a, HDMI 2.0b and Dual Link DVI. There is no USB-C, VGA or single link DVI.

This card requires at least a PCIe 3.0 x8 slot for maximum potential. Some GTX 1630 cards require a 6-pin power connector and some do not require any. The PSU recommendation is 300 W as this card uses 75 W of power.

The Nvidia GeForce GTX 1630 comes in at 5.7″ (1.45 cm) by 4.38″ (1.11 cm) and it is a 2 slot card. At release on the 28th June 2022, this card retailed for $169 USD.

View more GTX 1630 Variants here.

Specs

Purchase This Card

Amazon View Price At Amazon

General

Manufacturer Nvidia
Type Desktop
Series GeForce 16
Variant GTX 1630
GPU Architecture Turing
Code Name TU117-150-A1
Fabrication Process TSMC 12nm
Die Size 200 mm²
Base Clock 1.74 GHz
Boost Clock 1.785 GHz
Transistor Amount 4.7 billion
Cores 512 CUDA Cores
Texture Units 32
ROPs 16

Cores & Texture Config

Cores 512 CUDA Cores
Texture Units 32
ROPs 16
Tensor Cores 1024
L2 Cache 1MB
Infinity Cache -

Memory

Memory Size 4GB GDDR6
Memory Type GDDR5
Memory Clock 1500 MHz
Memory Clock Effective 12 Gbps
Memory Interface Width 64-bit
Memory Bandwidth 96.00 GB/s

Performance

Single Precision 1827.84 GFLOPS
Double Precision 57.12 GFLOPS
Half Precision 3655.68 GFLOPS

Fillrate

Texture (GT/s) 57.12
Pixel (GP/s) 28.56

Technologies

DirectX® Version 12
G-Sync/FreeSync
OpenCL 3.0
OpenGL 4.6
Shader Model 6.7
Vulkan 1.3
SLI/Crossfire Ready
VR Ready
RGB Lighting
Extra Technologies Ray Tracing Cores, Tensor Cores, NVIDIA DLSS, NVIDIA Reflex, NVIDIA Broadcast, PCI Express Den 3, Resizable BAR, NVIDIA GeForce Experience, NVIDIA Ansel, NVIDIA Freestyle, NVIDIA Shadowplay, NVIDIA Highlights, Game Ready Drivers, NVIDIA Studio Drivers, NVIDIA Omniverse, NVIDIA GPU Boost, NVIDIA NVLink (SLI-Ready), NVIDIA Encoder(NVENC), NVIDIA Decoder(NVDEC).

Connectivity

Maximum resolution 7680x4320 @ 60Hz
Max HDMI Resolution 7680x4320 @ 60Hz
Max DP Resolution 7680x4320 @ 60Hz
Display Port 1.4a
HDMI 2.0b
USB-C No
Dual Link DVI Yes
Single Link DVI No
VGA No

Requirements

Interface PCIe 3.0 x8
Power Connectors 6-Pin (Sometimes None)
PSU Recommendation 300 W
Graphics Card Power 75 W

Dimensions

Length 5.7" (1.45 cm)
Width 4.38" (1.11 cm)
Height 0.71" (1.8 cm)
Slot Width 2 Slot

Extra Information

Price (at release) $169 USD
Weight -
Released 28 June, 2022
